High pressure globe valvev

HP9563R high-pressure globe valve suits high-pressure pipelines and other high-pressure multi-port devices and pipeline systems. It adopts a non-rising rod design, and the O-ring is durable. The panel-mounted bonnet can be installed with the panel hole. Large aluminium alloy handwheel is used for low torque operation under  pressure.

》Send Mail《
Categories: ,

Description

Technical Parameters

The maximum working pressure is 380 bar, and the safety factor is 4:1. Temperature range -40°C~165°C. All valves used for oxygen are cleaned according to the requirements of CGA G-4.1. 100% pass the factory test.
Air inlet connection thread: 1”-11.5NPSM RH
Air outlet connection thread: 1”11.5NPSM RHC=140mm
Main dimensions: A=86mm B=96mm

Material Selection

Primary material: valve body, valve cover, valve stem, valve seat, and valve stem sealing ring is made of high-quality brass (high-quality brass (HPb59-1)
Hand wheel: aluminium alloy
Seat packing: imported PCTFE
Sealing material: FKM, imported PTFE
